CNC Plate Laser Cutting Machine 3000W ±0.02mm Precision Customizable

  • 1
  • 2

Brand Name : D.K.HISTRON

Model Number : HC3015/3000W

Certification : CE，ISO9001

Place of Origin : China

MOQ : 1 set

Price : 12000-300000USD

Payment Terms : T/T

Supply Ability : 25 sets/month

Delivery Time : 45 DAYS

Packaging Details : suitable for long distance transport

Product Name : Laser cutting machine

Control System : CNC Controller with CAD/CAM software compatibility

Dimensions : 4000mm x 2000mm x 1500mm

Working Area : 1000mm x 2000mm (customizable)

Cutting Thickness : 0.5mm - 30mm (depending on material and power)

Cutting Method : Laser Cutting

Cooling System : Water Cooling System

Positioning Accuracy : ±0.03 mm

Repeat Positioning Accuracy : ±0.02 mm

Material Compatibility : Metal Plates (Steel, Stainless Steel, Aluminum, etc.)

Contact Now

CNC Fully Automatic New Laser Cutting Machine Available in Different Working Areas and Supports Customization
Product Overview

High-Performance Single Table CNC Fiber Laser Cutting Machine. This industrial-grade CNC fiber laser cutting machine delivers exceptional precision and speed for metal fabrication applications. Engineered with advanced servo motor technology and professional display software, it provides flexible processing options with simple, convenient operation.

Key Features & Benefits
  • Import original packaging fiber laser cutter machines, good beam quality, stable performance, without reflection lens and light path adjustment, maintenance free essentially, 100,000 hours working time
  • High rigidity machine bed, adopts exclusive standard annealing processing with high-temperature NC electric resistance furnace, ensure long-time stable precision of the machine tool
  • High transformation efficiency of fiber laser, which up to 30%, saving the working power consumption by a large margin, achieves low operating costs
  • Adopts the imported original guide transmission and servo motors, high precision, high speed
  • Smooth cutting edge, little deformation
  • Low power consumption, energy saving, overall power consumption 1/3-1/5 of the same power YAG machines, 3 times sheet metal cutting speed
  • Laser generated without gas, air can be used to cut sheet metal
Material Compatibility

Suitable for cutting stainless steel, carbon steel, alloy steel, silicon steel, galvanized steel sheet, nickel-titanium alloy, chromium-nickel-iron alloy, titanium alloy, and various other metal materials.

Technical Specifications
Item Specification
Model HC3015/3000W
Processing Area 3000mm * 1500mm Effective Cutting
Machine Frame High-strength sheet metal, fully welded with annealing treatment
X/Y Axis Drive Bochu S9 Motor
X/Y Axis Positioning Accuracy ±0.05mm
X/Y Axis Repeat Positioning Accuracy ±0.02mm
Laser Source Raycus 3000W
Cutting Head 310
Control System Bochu 2000E System
Maximum Cutting Thickness Carbon Steel 3mm
Input Power 380V, 50HZ, 100A
Product Images
CNC Plate Laser Cutting Machine 3000W ±0.02mm Precision Customizable CNC Plate Laser Cutting Machine 3000W ±0.02mm Precision Customizable CNC Plate Laser Cutting Machine 3000W ±0.02mm Precision Customizable CNC Plate Laser Cutting Machine 3000W ±0.02mm Precision Customizable CNC Plate Laser Cutting Machine 3000W ±0.02mm Precision Customizable
Frequently Asked Questions
Can you supply the relevant documentation?

Yes, we can provide most documentation including Certificates of Analysis/Conformance, Insurance, Origin, and other export documents where required.

Are you manufacturer or trading company?

D.K.HISTRON is a professional manufacturer of CNC sheet metal fabrication machinery and laser machines.

What is the product warranty?

We warrant our materials and workmanship. Our commitment is to your satisfaction with our products. In warranty or not, it is our company culture to address and resolve all customer issues to everyone's satisfaction.

How about the shipping fees?

The shipping cost depends on the way you choose to get the goods.
